Toyotomi Laser 531/532 Direct Vented Oil Miser Heater w/ WIFI
Product Description
The Laser 531 replaced the iconic Oil Miser OM23 and Laser 530 model heating unit. It has a new upgraded look but still the same great features. The Laser 531/532 is able to offer all the comfort a central heating unit would provide but at the fraction of the cost and space! This unit operates on K-1 Kerosene, No 1 Low Sulfur Fuel Oil, or Ultra Low Sulfur Heating Oil/Ultra Low Sulfur Diesel. The new style wall flue pipe helps make venting to exterior simple and easy. The piping is completely flexible and it adjusts to wall thickness. All you will see is a small vent cap on the outside.
The Toyotomi units were able to offer green energy for over 40 years, way before green was even a thing. They are able to offer the most fuel efficient, energy saving, heating systems available which allow you to use up to 50% less fuel for heating the same area. The easy to install vented heating systems do not require a chimney, ductwork, plumbing or electrical work. In addition to your main house, the Toyotomi direct vent heating systems are ideal heat sources for garages, basements, summer homes, hunting cabins, are now certified for mobile homes and manufactured housing.
Features
- 8,010 to 22,000 BTU
- WIFI Compatibility
- Compact Size
- Contemporary Design
- 4 Burner Modes (Includes Off)
- Safety "Shut-Off" System
- Programmable Weekly Timer with up to 30 Different On/Off Intervals
- Power Failure Recovery
- Cool to the Touch Top and Side Panel Cabinet
- Display Room Temperature, Set Temperature and Error Code
- Automatic Ignitor Cleaning System
- Only 2-3/4" Hole Needed in Wall for Flue Pipe
- Whisper Quiet Operation
- Easy Installation as Direct-Vent System Requires no Chimney or Special Ductwork
- Unit Warranty - 1 Year warranty On Unit from date of Purchase for Parts/Labor. After year 1 is up, the warranty is extended for 2 years on the Burner Pot, Heat Chamber, and Heat Exchanger. Extended warranty does not include Glass (Laser 60AT). The 2 year extended warranty is for parts only and does not include labor.
Specifications
| Model | Toyostove Laser 531/532 Vented Heating System |
| Fuel Type: | Ultra Low Sulfur Heating Oil (ULSHO), Ultra Low Sulfur Diesel Fuel (ULSD) (ASTM D975 S15), Low Sulfur No.1 Fuel (ASTM D396 S500), Or K-1 Kerosene (ASTM D3699) |
| Heating Efficiency | 87% (AFUE Rating) |
| Heating Rating | High - 22,000 BTU/h Med - 15,000 BTU/h Low - 8,000 BTU/H |
| Fuel Consumption | 0.17 Gal/Hr (high) 0.11 Gal/Hr (Medium) 0.06 Gal/Hr (Low) |
| Dimensions (W x H x D): | 19-5/8" x 23-5/8" x 16-1/2" |
| Weight: | 38 lbs. |
| Electrical Rating | 120V @ 60Hz |
| Preheat | 240W |
| Burning | 50W |
| Heating Area | 920 square feet (0 degree F) 1150 square feet (20 degree F) |
| Max Length of Vent Pipe System | Maximum 10ft, 3 bends or less |
| Vent Hole Pipe | 2-3/4"-3" Diameter |
| Type of Tank | External |
Optional Parts & Accessories
What's in the box?
1) Drip Tray - 20475929 *not pictured*
2) Wall Brackets - 20474962
1) Exhaust Extension pipe (s) - 20479856
1) Pipe Stopper - 20474964
2) Pipe Holder - 20479463
1) Flue Pipe - 20479891
1) Exhaust Air Cap - 20479845
1) Intake Air Cap - 20474949
3) Screw - 20474985
1) Spacer - 20478967
3) Screw - 20474272
1) Bent Joint - 20470484 Dimensions - 3 1/8" x 3 1/8"
2) L- Shaped Hoses - 20474925
1) Oil Catch - 20474925
2) Hose Band - 20474977
1) Inlet Hose - 20470651
